Der Aufbau des Champion-Tisches, Teil 2: Rand

Champion Table Build Part219

surface preparation with a Stanley #80 scraper

Champion Table Build Part218

the swirly walnut grain is difficult to plane but the scraper is able to deal with it efficiently

Champion Table Build Part201

beginning to fit the side rails and bread-board ends

Champion Table Build Part203

marking the end cuts with a sharp knife

Champion Table Build Part202

then creating a shoulder along that line with a chisel assures a clean cut without tearing the grain

Champion Table Build Part204

cutting along the shoulder with a sharp crosscut saw

Champion Table Build Part206

a small array of saws to do this job

Champion Table Build Part205

cutting the central breadboard tenon

Champion Table Build Part207

coming up to the other side with a pull-saw

Champion Table Build Part208

both ends of the table are now cut

Champion Table Build Part209

cutting the base of the tenon “cheeks”

Champion Table Build Part210

really no other position to accurately make this cut

Champion Table Build Part211

cutting away the “cheeks”

Champion Table Build Part212

the finished tenon, and a groove has been cut to receive a floating tongue to align the breadboard

Champion Table Build Part213

laying out the positions of the mortise and tenons on the side rails and breadboards

Champion Table Build Part214

cutting the tenon on the side rails

Champion Table Build Part216

checking for a tight fit. the side rails are attached with glued tongue and groove joints, while the breadboards are “floating”, held in place by a tongue and groove joint and two “draw-bored” mortise and tenon joints, which will allow for expansion and contraction where the grain intersects perpendicular rather than parallel, yet holding the boards tight to the edge of the table. Two opposing corners are pinned miters and the other two are mortised.  imagine the table being able to expand in width along the length of the two boards left long to see the allowance for seasonal cross grain movement.

Champion Table Build Part220

treating the edges before the final assembly

Champion Table Build Part217

drilling for the dowels for the pinned miter joints where the live edges come together

Champion Table Build Part221

a brad point drill marks the center of the tenon inside

Champion Table Build Part222

re-marking the tenon with an offset so that the dowel pin will “draw” it tight to the edge of the table.  the holes will be elongated laterally to allow for joint movement.

Champion Table Build Part223

altering geometry with violence

Champion Table Build Part224

shaping the dowel pins by pounding the straight oak through a succession of smaller holes drilled in a steel plate until they are round and the size I need

Champion Table Build Part225

nearly there

Champion Table Build Part227

a batch of pins

Champion Table Build Part226

planing a taper

Champion Table Build Part228

the taper will allow the pin to engage the offset hole in the tenon and slowly pull it tight

Champion Table Build Part230

pounding the pins home for the final assembly

Champion Table Build Part229

a little help form a ratchet strap to pull the center tight

Champion Table Build Part232

cutting away the exposed ends with a saw

Champion Table Build Part233

a tightly pinned joint

Champion Table Build Part234

the top all joined. there will be a considerable amount of detail work on the top yet, but first the base



A Portrait of the Workshop in April

The provision for me in my shop this past week:  cutting dovetails in black walnut for a chest, some goat-milk and lime paint for the butcher block legs, and finishing up the milling of the mighty locust.

Table Build in Red Oak Part 1

The following is part 1 of a photo essay on a rustic and a little bit twisty red oak hall table build.

Composing

Roughing out the leg spindles

Cutting the tenons to width

Establishing taper with a gouge

Breather, almost there

Leveling out with a jack plane

Down to size with the spoker

After shaping with an angle grinder and hand sanding through many grits

Leg # 2 at dawn

Side by side

Composing again

About 11 days left and a lot of work to go

Wood-rick and Dressing Oak

Here is my small woodrick inspired by the folks at Plimoth Plantation.  With a small door to admit the chickens.

From the top.

From the west



Dressing a plank of red oak.  The radius of the iron leaves tracks.

The iron with a pail-bottom radius takes heavy shavings.

Chainsaw-milled and well seasoned,

Cut just north of the heart with enough character to remain functional.

Hope Chest Drawer Case

Below is a group of photos of some details of the construction of the black walnut drawer carcass and the drawer fronts for the cherry and walnut hope chest.  Please click on any of the pictures to view larger.

The lower web/ frame for the bottom of the drawer unit, it is constructed of white oak with the front (visible) rail being walnut.

The drawer case with the web installed with tongue and groove

The main chest rests upon the drawer case

Flattening walnut drawer fronts with a jointer

A forged bench hook (I learned from Peter Follansbee)

The flattened and drawer fronts ready to be marked and cut to length

The drawer fronts wedged in their spots to see how they look.  Also the dividers have been installed with stopped dovetails.

Hope Chest

Pictured below is the beginings of a hope chest in cherry and walnut, primarily.  The pictures depict the joinery of the upper case of the chest, which is cherry, and will lit atop a narrower walnut case with a row of drawers.

Here the dovetails have been cut and the piece is clamped together in order to mark precisely the corresponding pins.

cutting the pins with a dovetail saw…

cutting out the majority of the waste with a coping saw…

chopping out the rest of the waste with a paring chisel…

the board with pins cut out on both ends…

the case dry fitted.
